The KTM RC390 is just weeks away from its official launch. The test mules of this fully faired version of KTM 390cc naked motorcycle, the 390 Duke, were caught several times. We also spotted photographs showcasing a warehouse full with RC390 motorcycles. But here is a video that explains the new RC390 in details along with its technical specifications and features.

The KTM RC390 will be powered by the same 375cc single-cylinder liquid-cooled engine that is found on the Duke 390 that will churn out around 45 PS of power and 35 Nm of torque. The engine will come mated to a 6 speed gearbox. The RC390 will also share the trellis frame, Metzeler tyres, instrument cluster and electrical from the 390 Duke. The RC390 will get a full fairing and clip-on handlebars. The RC390 will also get dual projector headlights and Daytime Running LED lights.

We expect KTM to price the RC390 between Rs 2.3-2.4 lakhs.

KTM RC 390 Specifications and Details:

ENGINE
DesignSingle-cylinder 4-stroke engine, water-cooled
Displacement373.2 cc
Bore89 mm
Stroke60 mm
Performance43 hp
Starting aidElectric starter
Transmission6 speed, claw shifted
Engine lubricationForced oil lubrication with 2 Eaton pumps
Primary gear ratio30:80
Secondary gear ratio15:45
Cooling systemLiquid cooling system, continuous circulation of cooling liquid with water pump
ClutchWet multi-disc clutch / mechanically operated
Ignition systemContactless, controlled, fully electronic ignition system with digital ignition timing adjustment
CHASSIS
FrameTubular space frame made from steel, powder-coated
ForkWP Suspension Up Side Down
Shock absorberWP Monoshock
Suspension travel front125 mm
Suspension travel rear150 mm
Brake system FrontDisc brake with four-pot brake caliper
Brake system RearDisc brake with one-pot brake caliper, floating brake discs
Brake discs – diameter Front300 mm
Brake discs – diameter Rear230 mm
Chain5/8 x 1/4” X‑Ring
Steering head angle66.5°
Wheel base1,340±15 mm
Ground clearance (unloaded)178.5 mm
Seat height (unloaded)820 mm
Total fuel tank capacity approx.10 litre Unleaded premium fuel (95 RON)
Dry weight147 kg
