The upcoming KTM RC200 has been spotted again and the latest KTM RC200 image comes from KTM RC390 – India Facebook Page, which came up with this image last evening. CLICK HERE for our KTM RC200 vs Honda CBR250R Spec Sheet comparison.
It may be noted that the KTM RC200 India launch is around the corner and the bike is expected to go on sale for a price of around INR 1,55,000. Powering the bike is the same 200 cc engine that powers the Duke 200. For the RC200, this engine would have a max power of 26 PS and is expected to have a slightly different torque curve. The biking fraternity of our country is already excited about the upcoming Katoom and the KTM RC200 is easily among the most awaited motorcycles of our country in recent times.
TECHNICAL SPECIFICATIONS
ENGINE
| Design | Single-cylinder, 4-stroke, spark-ignition engine, liquid-cooled |
|---|---|
| Displacement | 199.5 cm³ |
| Bore | 72 mm |
| Stroke | 49 mm |
| Performance | 19 kW (25 hp) |
| Starting aid | Electric starter |
| Transmission | 6-speed, claw shifted |
| Engine lubrication | Forced oil lubrication with 1 rotor pump |
| Primary gear ratio | 22:72 |
| Secondary gear ratio | 14:42 |
| Cooling system | Liquid cooling system, continuous circulation of cooling liquid with water pump |
| Clutch | Clutch in oil bath / mechanically operated |
| Ignition system | Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment |
CHASSIS
| Frame | Tubular space frame made from steel tubes, powder-coated |
|---|---|
| Fork | WP Suspension 4357 |
| Shock absorber | WP Suspension 4618 EM |
| Suspension travel front | 125 mm |
| Suspension travel rear | 150 mm |
| Brake system Front | Disc brake with four-pot brake caliper |
| Brake system Rear | Disc brake with one-pot brake caliper, floating brake discs |
| Brake discs – diameter front | 300 mm |
| Brake discs – diameter rear | 230 mm |
| Chain | 5/8 x 1/4” X‑Ring |
| Steering head angle | 66.5° |
| Wheel base | 1,340±15 mm |
| Ground clearance (unloaded) | 178.5 mm |
| Seat height (unloaded) | 820 mm |
| Total fuel tank capacity approx. | 10 l Unleaded premium fuel (95 RON) |
| dry weight | 137.5 kg |
