ABB Reveals The Future Of Customized Painting With PixelPaint

Added in: News

In these days of Dual-Tone exteriors, where we are driving demand for greater individualization, there is an increasing need for customized vehicle paint schemes, using either a second colour, an entirely different paint finish such as matte, or a special design.

Today, applying a two-tone or customized design onto the bodywork of a car is not only time consuming, but also a labour-intensive process that required the vehicle to be put through the painting line twice, once for the first layer and then, after the areas had been masked, again for the second colour. Typically, masking the bodywork required around 10 to 20 operators per shift, with two operators also needed to de-mask it after the second colour has been applied. We believe ABB has a solution to this problem, which can be seen in their recent video:

With only 70 to 80 per cent of the paint being applied to the bodywork surface, significant quantities of paint is completely wasted, increasing costs through recycling and having to purchase additional paint.

ABB’s innovative PixelPaint solution incorporates a high painting inkjet head, dosing control package and easy to use RobotStudio programming software for two-tone and decorative painting applications.

ABB pixel paint benifits

“In today’s fiercely competitive automotive manufacturing market, vehicle producers need solutions that can help them to improve their flexibility, efficiency and cost competitiveness while delivering a high-quality paint finish, including individualized options to meet the growing demand for non-standard and customized designs,” said Michael Larsson, Managing Director Automotive OEM for ABB Robotics. “With PixelPaint, 100 per cent of the paint is applied to the bodywork surface, so there’s no overspray. Not only does this reduce operating costs and improve environmental performance by ensuring that no paint is lost, but PixelPaint also eliminates the process of masking and de-masking each car, helping to reduce bottlenecks in automotive paint shops.”

ABB pixel painter

Pixelpaint is available as a cell using two ABB IRB 5500 robots.  The non-overspray technology prints paint directly on to a target area using the printing nozzle head instead of spraying with a conventional atomizer, resulting in 100 per cent transfer efficiency.

With no need for masking or de-masking, a customized paint job can be carried out in a single pass, reducing cycle times by around 50 per cent. ABB’s non-overspray PixelPaint solution was recognized as a groundbreaking innovation with a “Technology” award at the SURCAR annual conference in Cannes in June 2019 and in case you are wondering, SURCAR is a forum for the global car body finishing community.

Benifits of ABB pixel painter

In addition to robots and application-specific equipment, ABB also offers standardized production cells for the automotive industry, as well as the design, planning and implementation of complete production lines. The ABB Ability platform enables customers to benefit from various digital services such as process optimization, and predictive maintenance.

PixelPaint will be unveiled at the China International Industry Fair (CIIF) in Shanghai on September 15.
